Streaming console gameplay to Twitch or YouTube starts with one small box: the capture card. It takes the HDMI signal from your PS5, Xbox, or Switch, passes it through to your TV with no added lag, and sends a copy to your PC for broadcasting. Setup is simpler than most people expect, and once the cables are in the right ports the software side takes about ten minutes.
This guide covers the full process: connecting the card, configuring your console, adding the feed to OBS Studio, and fixing the handful of problems that trip up first streams. If you have not chosen your hardware yet, start with our roundup of the best capture cards for streaming to match a card to your console and budget.
What You Need Before You Start
- A capture card with HDMI input and passthrough output. External USB models are the easiest starting point, and any pick from our capture card guide will work with the steps below.
- Two HDMI cables rated for your target resolution, plus the USB cable included with the card. Use the cable that came in the box first, since capture cards are picky about USB bandwidth.
- A PC or laptop for encoding. It does not need to be a monster, though a dedicated machine such as one of the best compact gaming PCs for streaming keeps game performance and stream encoding separate.
- OBS Studio or the capture card maker’s own app installed on that PC.
Our pick for this guide: Elgato HD60 X Capture Card
A 1080p60 HDMI passthrough card that matches the PS5, Xbox and Switch setup steps in this guide.
Step 1: Connect the Capture Card
- Plug an HDMI cable from your console’s HDMI out into the port labeled IN on the capture card.
- Run the second HDMI cable from the card’s OUT port to your TV or monitor. This passthrough connection is what you play on, so lag never touches your gameplay.
- Connect the card to your PC with the supplied USB cable. Plug it into a rear motherboard port when possible, and match the port type the manufacturer’s documentation calls for, since many cards require USB 3.0 or better.
- Power on the console. Your TV should show gameplay exactly as before, which confirms passthrough is working.
Step 2: Configure the Console
- On PS5, open Settings, go to System, then HDMI, and disable HDCP. Copy protection is meant for streaming apps, but while it is on, most capture cards show a black screen.
- On Switch, use the dock, since the console only outputs HDMI when docked. Set the resolution to 1080p in System Settings under TV Output.
- On Xbox, HDCP is disabled for games automatically, but check Settings under General and TV options to match your resolution to what your card supports.
- Set the console’s output resolution and frame rate to something your card can capture, typically 1080p at 60 frames per second for entry-level cards.
Step 3: Add the Feed to OBS and Go Live
- Open OBS Studio, click the plus icon under Sources, and choose Video Capture Device.
- Select your capture card from the Device dropdown. Gameplay should appear in the preview within a few seconds.
- In the same source properties, set the audio output mode to capture audio from the device, then confirm the audio meter moves in the OBS mixer.
- In OBS Settings under Video, match the canvas and output resolution to your capture resolution to avoid blurry scaling.
- Add your webcam and overlays as separate sources. Our guide to setting up a webcam for streaming covers placement and lighting.
- Run a private test recording before your first live stream, and consider one of the best stream decks to switch scenes and mute audio without alt-tabbing out of your game.
Troubleshooting Common Problems
A black screen in OBS almost always means HDCP is still enabled on a PlayStation, the card is plugged into an underpowered USB port, or another app such as the manufacturer’s own software has locked the device. Close every other capture app before opening OBS. If the picture appears but stutters, lower the capture resolution or move the USB cable to a different controller on the PC. Audio that drifts out of sync can usually be fixed with a small sync offset on the capture source in the OBS advanced audio properties. And if your TV shows nothing at all, swap the two HDMI cables, since a cable rated below the passthrough resolution is the usual culprit.
Frequently asked questions
Does a capture card add lag to my gameplay?
Not on the passthrough connection. You play on the signal that goes straight through the card to your TV, which is effectively lag-free. The slight delay you see in OBS only affects the stream, not your controls.
Why is my capture card showing a black screen on PS5?
The most common cause is HDCP. Open the PS5 Settings, go to System and then HDMI, and turn HDCP off. If the screen is still black, try a different USB port and confirm both HDMI cables are fully seated.
Can I stream from a console without a capture card?
Yes, PS5 and Xbox have built-in Twitch or YouTube streaming, but you give up overlays, alerts, custom scenes, and higher bitrates. A capture card routed through OBS on a PC produces a noticeably more professional stream.
Do I need a powerful PC to use a capture card?
For 1080p60 streaming, a mid-range PC from the last few years is enough, especially if it has a modern GPU encoder. The console does the gaming work, so your PC only handles encoding and overlays.
